EAGLEFORS ATX
The popular EAGLEFORS ATX combines versatility and distinctive design into on and off road traction, ride comfort and reliability, more struggling than normal AT tire in various road conditions.
Performance
Suv
All Season
Get a one-stop solution
In order to make sure your question or comment reaches the right people, please fil out the brief form and we’ll respond as soon as possible Your private information is absolutely protected.
Strength engineering and central large blocks deliver off-road traction + on-roadstability.
Rugged and extended over-the-shoulder tread for engough griping and cutsprevented in harsh off-roading.
Wide-narrow groove arangement reduces road noise and improves traction.
Strong inner structure+optimally biting edges: better handling,stable dirt/mud/snowperformance, quiet rides.
Spec
- 17"
- 18"
- 19"
- 20"
- 22"
- 24"
| Size Description |
Tread Depth MM 1/32" |
Sidewall | Standard Rim |
Section Width (mm) |
OA. Diameter (mm) |
Max. Pressure (kpa/psi) |
M+S | ||
| P225/65R17 | 102T | 9 | 11.3 | RWL | 6.5 | 228 | 724 | 300/44 | √ |
| P235/65R17 | 104T | 9 | 11.3 | RWL | 7 | 240 | 738 | 300/44 | √ |
| P245/65R17 | 111TXL | 9 | 11.3 | RWL | 7 | 248 | 750 | 340/50 | √ |
| P245/70R17 | 110T | 9 | 11.3 | RWL | 7 | 248 | 776 | 300/44 | √ |
| Size Description |
Tread Depth MM 1/32" |
Sidewall | Standard Rim |
Section Width (mm) |
OA. Diameter (mm) |
Max. Pressure (kpa/psi) |
M+S | ||
| LT305/65R17 | 121/118S | 11.3 | 14.2 | RWL | 9 | 311 | 828 | 450/65 | √ |
| LT315/70R17 | 121/118S | 11.3 | 14.2 | RWL | 9.5 | 323 | 874 | 450/65 | √ |
| Size Description |
Tread Depth MM 1/32" |
Sidewall | Standard Rim |
Section Width (mm) |
OA. Diameter (mm) |
Max. Pressure (kpa/psi) |
M+S | ||
| P235/60R18 | 107TXL | 9 | 11.3 | RWL | 7 | 240 | 739 | 340/50 | √ |
| P245/60R18 | 105T | 9 | 11.3 | RWL | 7 | 248 | 751 | 300/44 | √ |
| Size Description |
Tread Depth MM 1/32" |
Sidewall | Standard Rim |
Section Width (mm) |
OA. Diameter (mm) |
Max. Pressure (kpa/psi) |
M+S | ||
| LT285/65R18 | 125/122S | 11.3 | 14.2 | RWL | 8.5 | 292 | 827 | 550/80 | √ |
| LT285/75R18 | 129/126R | 11.3 | 14.2 | RWL | 8 | 286 | 885 | 550/80 | √ |
| LT305/70R18 | 126/123R | 11.3 | 14.2 | RWL | 9 | 311 | 885 | 450/65 | √ |
| LT325/65R18 | 127/124S | 11.3 | 14.2 | RWL | 9.5 | 331 | 879 | 450/65 | √ |
| Size Description |
Tread Depth MM 1/32" |
Sidewall | Standard Rim |
Section Width (mm) |
OA. Diameter (mm) |
Max. Pressure (kpa/psi) |
M+S | ||
| P235/55R19 | 105TXL | 9 | 11.3 | RWL | 7.5 | 245 | 741 | 340/50 | √ |
| P245/55R19 | 103T | 9 | 11.3 | RWL | 7.5 | 253 | 753 | 300/44 | √ |
| Size Description |
Tread Depth MM 1/32" |
Sidewall | Standard Rim |
Section Width (mm) |
OA. Diameter (mm) |
Max. Pressure (kpa/psi) |
M+S | ||
| P245/50R20 | 102T | 9 | 11.3 | RWL | 7.5 | 253 | 754 | 300/44 | √ |
| P255/50R20 | 109TXL | 9 | 11.3 | RWL | 8 | 265 | 764 | 340/50 | √ |
| Size Description |
Tread Depth MM 1/32" |
Sidewall | Standard Rim |
Section Width (mm) |
OA. Diameter (mm) |
Max. Pressure (kpa/psi) |
M+S | ||
| LT285/55R20 | 122/119S | 11.3 | 14.2 | RWL | 9 | 297 | 822 | 550/80 | √ |
| LT285/60R20 | 125/122S | 11.3 | 14.2 | RWL | 8.5 | 292 | 850 | 550/80 | √ |
| LT295/60R20 | 126/123R | 11.3 | 14.2 | RWL | 8.5 | 299 | 862 | 550/80 | √ |
| LT305/55R20 | 121/118S | 11.3 | 14.2 | RWL | 9.5 | 316 | 844 | 450/65 | √ |
| 33X12.50R20LT | 114R | 11.3 | 14.2 | RWL | 10 | 318 | 826 | 450/65 | √ |
| 35X12.50R20LT | 125R | 11.3 | 14.2 | RWL | 10 | 318 | 877 | 550/80 | √ |
| Size Description |
Tread Depth MM 1/32" |
Sidewall | Standard Rim |
Section Width (mm) |
OA. Diameter (mm) |
Max. Pressure (kpa/psi) |
M+S | ||
| P275/50R22 | 115HXL | 9 | 11.3 | RWL | 8.5 | 284 | 835 | 340/50 | √ |
| P285/45R22 | 114HXL | 9 | 11.3 | RWL | 9.5 | 285 | 815 | 340/50 | √ |
| Size Description |
Tread Depth MM 1/32" |
Sidewall | Standard Rim |
Section Width (mm) |
OA. Diameter (mm) |
Max. Pressure (kpa/psi) |
M+S | ||
| 33X12.50R22LT | 109S | 11.3 | 14.2 | RWL | 10.5 | 316 | 826 | 450/65 | √ |
| 35X12.50R22LT | 121R | 11.3 | 14.2 | RWL | 10 | 318 | 877 | 450/65 | √ |
| Size Description |
Tread Depth MM 1/32" |
Sidewall | Standard Rim |
Section Width (mm) |
OA. Diameter (mm) |
Max. Pressure (kpa/psi) |
M+S | ||
| 35X12.50R24LT | 116R | 11.3 | 14.2 | RWL | 10.5 | 316 | 877 | 550/80 | √ |
| 37X13.50R24LT | 124R | 11.3 | 14.2 | RWL | 11 | 345 | 928 | 550/80 | √ |
