EAGLEFORS H/T
The EAGLEFORS H/T, as a all-season light truck highway tire, is engineered to make the most of your on-road driving. Available in a wide range of sizes and offers an upgraded ride quality and versatile look for your light truck, suv, or crossover vehicle.
Performance
Get a one-stop solution
In order to make sure your question or comment reaches the right people, please fil out the brief form and we’ll respond as soon as possible Your private information is absolutely protected.
Symmetric, non-directional tread design enable easier rotations in turn to reduce irregular wear with continuous shoulder design.

Optimized central 3-rib design provides increased dry and wet traction while improving highway stability.

Four deep and wide circumferential grooves to efficiently evacuate water and slush for better all season traction.

Vairous block pitches arrangement to reduce road noise for a more comfortable ride. Variable angle lateral grooves and sipes improve the wear life by minimizing irregular wear and for a smoother, quieter ride.

Spec
- 16"
- 17"
- 18"
- 19"
- 20"
| Size | LI / SR | XL | Tread Depth MM 1/32" |
Sidewall | Standard Rim | Section Width(mm) | OA.Diameter(mm) | Max. Pressure (kpa/psi) |
M+S | |
| 235/65R16C | 121/119R | 8.3 | 10.5 | BSW | 7 | 240 | 712 | 575/83 | √ | |
| LT215/85R16 | 115/112S | 8.3 | 10.5 | BSW | 6 | 216 | 772 | 550/80 | √ | |
| LT225/75R16 | 115/112S | 9.1 | 11.5 | BSW | 6 | 223 | 744 | 550/80 | √ | |
| LT235/85R16 | 120/116S | 9.1 | 11.5 | BSW | 6.5 | 235 | 806 | 550/80 | √ | |
| LT245/75R16 | 120/116S | 9.1 | 11.5 | BSW | 7 | 248 | 774 | 550/80 | √ | |
| LT265/75R16 | 123/120S | 9.9 | 12.5 | BSW | 7.5 | 267 | 804 | 550/80 | √ | |
| Size | LI / SR | XL | Tread Depth MM 1/32" |
Sidewall | Standard Rim | Section Width(mm) | OA.Diameter(mm) | Max. Pressure (kpa/psi) |
M+S | |
| LT235/80R17 | 120/117R | 9.1 | 11.5 | BSW | 6.5 | 235 | 808 | 550/80 | √ | |
| LT245/70R17 | 119/116S | 9.1 | 11.5 | BSW | 7 | 248 | 776 | 550/80 | √ | |
| LT245/75R17 | 121/118S | 9.1 | 11.5 | BSW | 7 | 248 | 800 | 550/80 | √ | |
| LT265/70R17 | 123/120S | 9.1 | 11.5 | BSW | 8 | 272 | 804 | 550/80 | √ | |
| Size | LI / SR | XL | Tread Depth MM 1/32" |
Sidewall | Standard Rim | Section Width(mm) | OA.Diameter(mm) | Max. Pressure (kpa/psi) |
M+S | |
| LT275/65R18 | 123/120S | 9.9 | 12.5 | BSW | 8 | 279 | 815 | 550/80 | √ | |
| LT275/70R18 | 125/122S | 9.9 | 12.5 | BSW | 7 | 248 | 801 | 550/80 | √ | |
| Size | LI / SR | XL | Tread Depth MM 1/32" |
Sidewall | Standard Rim | Section Width(mm) | OA.Diameter(mm) | Max. Pressure (kpa/psi) |
M+S | |
| 235/55R19 | 105V | XL | 8.3 | 10.5 | BSW | 7.5 | 245 | 741 | 340/50 | √ |
| 245/55R19 | 107V | XL | 8.3 | 10.5 | BSW | 7.5 | 235 | 753 | 340/50 | √ |
| Size | LI / SR | XL | Tread Depth MM 1/32" |
Sidewall | Standard Rim | Section Width(mm) | OA.Diameter(mm) | Max. Pressure (kpa/psi) |
M+S | |
| 235/55R20 | 102V | 8.3 | 10.5 | BSW | 7.5 | 245 | 766 | 300/44 | √ | |
| 245/50R20 | 102V | 8.3 | 10.5 | BSW | 7.5 | 253 | 754 | 300/44 | √ | |
| 255/50R20 | 109V | XL | 8.3 | 10.5 | BSW | 8 | 265 | 764 | 340/50 | √ |
| 265/50R20 | 111V | XL | 8.3 | 10.5 | BSW | 8.5 | 277 | 774 | 340/50 | √ |
| 275/55R20 | 117V | XL | 8.3 | 10.5 | BSW | 8.5 | 284 | 810 | 340/50 | √ |
| 275/60R20 | 115V | 8.3 | 10.5 | BSW | 8 | 279 | 838 | 300/44 | √ | |
